JOHNSON CONTROLS
24
FORM 150.62-NM6 (103)
Installation
(One Field Provided Power Supply Circuit to the chiller. Field connections to Factory Provided Terminal Block (optional), Non-Fused Discon-
nect Switch (optional) or Circuit Breaker (optional).)
ELECTRICAL DATA – SINGLE POINT POWER SUPPLY CONNECTIONS – YCAL0040E_ - YCAL0080E_
TABLE 4 – SINGLE POINT POWER SUPPLY CONNECTIONS
MODEL
YCAL
VOLT HZ
SINGLE POINT FIELD SUPPLIED WIRING
MCA
1
MIN N/F
DISC SW
2
D.E. FUSE CKT. BKR.
5
INCOMING (LUGS) WIRE RANGE
6
TERMINAL
BLOCK (opt)
NF DISC.
SWITCH (opt)
CIRCUIT
BREAKER (opt)
MIN
3
MAX
4
MIN MAX
0040
200 60 174 200 200 200 200 200 # 10 - 3/0 # 6 - 350 # 3 - 300
230 60 173 200 200 200 200 200 # 10 - 3/0 # 6 - 350 # 3 - 300
380 60 104 150 110 110 110 110 # 10 - # 1 # 2 - 4/0 # 2 - 4/0
460 60 87 100 100 100 100 100 # 10 - # 1 # 14 - 1/0 # 14 - 1/0
575 60 69 100 80 80 80 80 # 10 - # 1 # 14 - 1/0 # 14 - 1/0
0042
200 60 190 250 200 225 200 225 # 10 - 300 # 6 - 350 # 3 - 300
230 60 188 250 200 225 200 225 # 10 - 300 # 6 - 350 # 3 - 300
380 60 113 150 125 125 125 125 # 10 - # 1 # 2 - 4/0 # 2 - 4/0
460 60 94 150 100 110 100 110 # 10 - # 1 # 2 - 4/0 # 14 - 1/0
575 60 75 100 80 90 80 90 # 10 - # 1 # 14 - 1/0 # 14 - 1/0
0044
200 60 203 250 225 225 225 225 # 10 - 300 # 6 - 350 # 3 - 300
230 60 202 250 225 225 225 225 # 10 - 300 # 6 - 350 # 3 - 300
380 60 122 150 150 125 150 125 # 10 - 3/0 # 2 - 4/0 # 2 - 4/0
460 60 101 150 110 110 110 110 # 10 - # 1 # 2 - 4/0 # 2 - 4/0
575 60 81 100 90 90 90 90 # 10 - # 1 # 14 - 1/0 # 14 - 1/0
0050
200 60 221 250 250 250 250 250 # 10 - 300 # 6 - 350 # 6 - 350
230 60 219 250 250 250 250 250 # 10 - 300 # 6 - 350 # 6 - 350
380 60 132 150 150 150 150 150 # 10 - 3/0 # 2 - 4/0 # 2 - 4/0
460 60 110 150 125 125 125 125 # 10 - # 1 # 2 - 4/0 # 2 - 4/0
575 60 88 100 100 100 100 100 # 10 - # 1 # 14 - 1/0 # 14 - 1/0
0060
200 60 236 400 250 250 250 250 # 10 - 300 250-500 # 6 - 350
230 60 235 400 250 250 250 250 # 10 - 300 250-500 # 6 - 350
380 60 142 200 150 150 150 150 # 10 - 3/0 # 6 - 350 # 2 - 4/0
460 60 118 150 125 125 125 125 # 10 - 3/0 # 2 - 4/0 # 2 - 4/0
575 60 94 150 100 110 100 110 # 10 - # 1 # 2 - 4/0 # 14 - 1/0
0064
200 60 263 400 300 300 300 300 # 4 - 500 250-500 250-500
230 60 261 400 300 300 300 300 # 4 - 500 250-500 250-500
380 60 157 200 175 175 175 175 # 10 - 3/0 # 6 - 350 # 2 - 4/0
460 60 131 150 150 150 150 150 # 10 - 3/0 # 2 - 4/0 # 2 - 4/0
575 60 105 150 110 110 110 110 # 10 - # 1 # 2 - 4/0 # 2 - 4/0
0070
200 60 283 400 300 300 300 300 # 4 - 500 250-500 250-500
230 60 282 400 300 300 300 300 # 4 - 500 250-500 250-500
380 60 170 200 200 200 200 200 # 10 - 3/0 # 6 - 350 # 4 - 300
460 60 141
200 150 150 150 150 # 10 - 3/0 # 6 - 350 # 2 - 4/0
575 60 113 150
125 125 125 125 # 10 - # 1 # 2 - 4/0 # 2 - 4/0
0074
200 60 309 400 350 350 350 350 # 4 - 500 250-500 250-500
230 60 307 400 350 350 350 350 # 4 - 500 250-500 250-500
380 60 185 250 200 200 200 200 # 10 - 300 # 6 - 350 # 4 - 300
460 60 154 200 175 175 175 175 # 10 - 3/0 # 6 - 350 # 4 - 300
575 60 123 150 150 125 150 125 # 10 - 3/0 # 2 - 4/0 # 2 - 4/0
0080
200 60 332 400 350 350 350 350 # 4 - 500 250-500 250-500
230 60 330 400 350 350 350 350 # 4 - 500 250-500 250-500
380 60 199 250 225 225 225 225 # 10 - 300 # 6 - 350 # 4 - 300
460 60 166 200 175 175 175 175 # 10 - 3/0 # 6 - 350 # 4 - 300
575 60 132 150 150 150 150 150 # 10 - 3/0 # 2 - 4/0 # 2 - 4/0
"Replacement
information at
back of manual"
