JOHNSON CONTROLS
87
FORM 150.62-NM6 (103)
Displays the number of fan stages in the system active
at the time of the fault.
Displays the system amperage (calculated approxi-
mately) and, DC feedback voltage from the 2ACE
Module, at the time of the fault.
For this message to appear, CURRENT FEEDBACK
ONE PER SYSTEM must be programmed under the op-
tions key. If the micro is programmed as one CURRENT
FEEDBACK ONE PER UNIT under the program key, the
display will be the rst display prior to the SYS 1 info. If
the micro is programmed for CURRENT FEEDBACK
NONE, no current display will appear.
Displays for System 1 starting with SYS X NUMBER OF
COMPS RUNNING X through SYS X AMPS = XXX.X
VOLTS = X.X will be displayed rst, followed by displays
for System 2.
Further explanation of the above displays is covered un-
der the STATUS, OPER DATA, COOLING SETPOINTS,
PROGRAM, and OPTIONS keys.
S Y S X F A N S T A G E X X X
S Y S X A M P S = 4 0 . 3
V O L T S = 2 . 2
2
