Figure 1: YHAU-C components
Components
A Cooling Water Inlet
B Touch Panel Display
C Control Panel
D Cooling Water Outlet
E Chilled Water Inlet
F Absorber
G Solution spray pump
H Evaporator
I Solution Circulation Pump
13YHAU-C Single Effect Steam-Fired Absorption Chiller
