Johnson Controls York YHAU-C User Manual

2-Wire Type Cable Diagrams
The following is a sample cable diagram for a 2-wire type connection. It uses a GP4000 series
(COM2).
Figure 45: 2-Wire 1:1 connection with user-created cable
Figure 46: 2-Wire n:1 connection with user-created cable
YHAU-C Single Effect Steam-Fired Absorption Chiller94
