Johnson Controls ZST06 User Manual

5566019-BIM-B-1118
Johnson Controls Ducted Systems 27
ZS-06 through -12 standard motor - with powered convenience outlet
Size
(tons)
Volt
Compressors
(each)
OD fan
motors
(each)
Supply
blower
motor
Pwr exh
motor
Pwr
conv
outlet
Electric heat option
MCA
1
(amps)
MCA
1
with pwr
exh (amps)
Max fuse
2
/
breaker
3
size (amps)
Max fuse
2
/
breaker
3
size with
pwr exh
(amps)
RLA LRA MCC FLA FLA FLA FLA Model kW Stages Amps
-06
(6)
208 11.2 84 18 2.1 5.2 5.5 20
None - - - 44.6 50.1 50 60
E09 6.8 1 18.9 44.6 50.1 50 60
E18 13.5 2 37.5 65.9 72.8 70 80
E24 18 2 50 81.5 88.4 90 90
E36 25.5 2 70.8 107.5 114.4 110 125
230 11.2 84 18 2.1 5.2 5.5 20
None - - - 44.6 50.1 50 60
E09 9 1 21.7 46.1 53 50 60
E18 18 2 43.3 73.1 80 80 80
E24 24 2 57.7 91.1 98 100 100
E36 34 2 81.8 121.3 128.1 125 150
460 5.6 44 9 1.26 2.6 2.2 20
None - - - 22.7 24.9 25 30
E09 9 1 10.8 23 25.8 25 30
E18 18 2 21.7 36.6 39.4 40 40
E24 24 2 28.9 45.6 48.4 50 50
E36 34 2 40.9 60.6 63.4 70 70
575 3.8 34 6 0.66 2 1.8 20
None - - - 15.9 17.7 20 20
E09 9 1 8.7 18.4 20.6 20 25
E18 18 2 17.3 29.1 31.4 30 35
E24 24 2 23.1 36.4 38.6 40 40
E36 34 2 32.7 48.4 50.6 50 60
-07
(7.5)
208 13.8 83.1 22 2.1 5.2 5.5 20
None - - - 50.5 56 60 60
E09 6.8 1 18.9 50.5 56 60 60
E18 13.5 2 37.5 65.9 72.8 70 80
E24 18 2 50 81.5 88.4 90 90
E36 25.5 2 70.8 107.5 114.4 110 125
230 13.8 83.1 22 2.1 5.2 5.5 20
None - - - 50.5 56 60 60
E09 9 1 21.7 50.5 56 60 60
E18 18 2 43.3 73.1 80 80 80
E24 24 2 57.7 91.1 98 100 100
E36 34 2 81.8 121.3 128.1 125 150
460 6.2 41 10 1.26 2.6 2.2 20
None - - - 24.1 26.3 30 30
E09 9 1 10.8 24.1 26.3 30 30
E18 18 2 21.7 36.6 39.4 40 40
E24 24 2 28.9 45.6 48.4 50 50
E36 34 2 40.9 60.6 63.4 70 70
575 4.9 33 8 0.66 2 1.8 20
None - - - 18.3 20.1 20 25
E09 9 1 8.7 18.4 20.6 20 25
E18 18 2 17.3 29.1 31.4 30 35
E24 24 2 23.1 36.4 38.6 40 40
E36 34 2 32.7 48.4 50.6 50 60
-08
(8.5)
208 14.5 98 23 3.03 6.8 5.5 20
None - - - 55.5 61 70 70
E09 6.8 1 18.9 55.5 61 70 70
E18 13.5 2 37.5 67.9 74.8 70 80
E24 18 2 50 83.5 90.4 90 100
E36 25.5 2 70.8 109.5 116.4 110 125
230 14.5 98 23 3.03 6.8 5.5 20
None - - - 55.5 61 70 70
E09 9 1 21.7 55.5 61 70 70
E18 18 2 43.3 75.1 82 80 90
E24 24 2 57.7 93.1 100 100 100
E36 34 2 81.8 123.3 130.1 125 150
460 6.3 55 10 1.6 3.4 2.2 20
None - - - 25.8 28 30 30
E09 9 1 10.8 25.8 28 30 30
E18 18 2 21.7 37.6 40.4 40 45
E24 24 2 28.9 46.6 49.4 50 50
E36 34 2 40.9 61.6 64.4 70 70
575 6 41 9 1.35 2.4 1.8 20
None - - - 22.6 24.4 25 30
E09 9 1 8.7 22.6 24.4 25 30
E18 18 2 17.3 29.6 31.9 30 35
E24 24 2 23.1 36.9 39.1 40 40
E36 34 2 32.7 48.9 51.1 50 60
