Johnson Controls ZST06 User Manual

5566019-BIM-B-1118
Johnson Controls Ducted Systems 33
Optional electric heat
The factory-installed heaters are wired for single point power
supply. You only need to bring the power supply into the single
point terminal block.
These CSA approved heaters are located within the central
compartment of the unit with the heater elements extending in
to the supply air chamber.
Fuses are supplied, where required, by the factory. Some kW
sizes require fuses and others do not. See the Electric heat
minimum supply air table for minimum CFM limitations. See the
Electrical data table for electrical data.
Table 15:Electric heat minimum supply air
Size (tons) Model Voltage
Minimum supply air (CFM)
Heater kW
9 18243654
-06
(6.5)
ZS
208/230-3-60 1950 1950 1950 1950 -
460-3-60 1950 1950 1950 1950 -
600-3-60 1950 1950 1950 1950 -
-07
(7.5)
ZS
208/230-3-60 2250 2250 2250 2250 -
460-3-60 2250 2250 2250 2250 -
600-3-60 2250 2250 2250 2250 -
-08
(8.5)
ZS
208/230-3-60 2550 2550 2550 2550 -
460-3-60 2550 2550 2550 2550 -
600-3-60 2550 2550 2550 2550 -
-10
(10)
ZS
208/230-3-60 - 3000 3000 3000 3500
460-3-60 - 3000 3000 3000 3000
600-3-60 - 3000 3000 3000 3500
-12
(12.5)
ZS
208/230-3-60 - 3750 3750 3750 4000
460-3-60 - 3750 3750 3750 3750
600-3-60 - 3750 3750 3750 3750
