©2015 Johnson Level & Tool 21
9. Technical Specifications
Laser Wavelength 635nm±10nm
Laser Classification Class IIIa
Maximum Power Output ≤5mW
Accuracy ±1/8"/100 ft. (±1mm/10m)
Interior Range Up to 200 ft. (60m) diameter depending
on light conditions
Exterior Range Up to 2000 ft. (600m) diameter with
detector
Auto-Leveling Range ±5°
Power Supply Rechargeable battery pack
or 6.4V adapter (included)
4 “C” alkaline batteries (not included)
Battery Life
24 hours with rechargeable battery pack;
36 hours with alkaline batteries
Dimensions 8.62" x 6.30" x 7.95"
(219 x 160 x 202mm)
Weight 4.65 lbs. (2Kg)
Working Temperature 14°F to 113°F (-10°C to 45°C)
Center Screw Thread 5/8" – 11
Rotation Speed 600 rpm
IP Protection Class 65
8488H-English_Manuals 11/11/14 2:36 PM Page 21
