E 7000 CONTROL BOARD WIRING DIAGRAM
A2
A4 A1 A3
¾ A1 : 3-pin terminal to the electromagnet brake set
¾ A2 : 2-pin terminal to the adapter
¾ A3 : 3-pin terminal to the console
¾ A4: grounding wire to frame
3-2
