Johnson E7000 Service Manual

Console Diagnostics Mode
STEP 1
STEP 2
STEP 3
STEP 4
1. Sit on your bike, Press and hold down the
"RESET” key then start pedaling to reach a
pedal speed of approximately 30rpm. Dot Matrix
Display will be scanned slowly starting from LEDs
of the bottom row to the top; each segment of the
7-segments will be scanned simultaneously
 If one of LEDS is not lit, replace the PCB.
1. Press the ENTER key.
2. Dot Matrix Display will be scanned slowly starting
from LEDs at the leftmost column to the right.
3. Each 7-segments display will be scanned one by
one.
 If one of LEDS is not lit, replace the PCB.
1. Press the ENTER key.
2. Dot Matrix and 7-segments will display lighted up
 If one of LEDS is not lit, replace the PCB.
1. Press the ENTER key.
2. Dot Matrix Display will show “RPM”.
3. “RPM” window will show current RPM
4. “TIME” window will show total accumulated
minutes and seconds.
5. “AGE” window will show total accumulated hour.
6. Hold down the ”RESET” key first then press
“PAUSE” key to clear the record.
4-8
