PULLEY AXLE REPLACEMENT PROCEDURE
Tools required:
5-10
Philips
screwdriver
Hex key
(6mm)
C-Clip Pliers
Wooden
hammer
Adjustable
wrench
Procedure:
1 Remove all of the covers
and poly v belts.
2 Remove the screw (A) and
washer
3 Pull pulley (B) out then
knock axle set out with the
wooden hammer.
4 Remove the nut (C), then
tap the axle out
5 Replace the axle with a
new one, then install the
c-clip by using c-clip
pliers.
6 Reverse the step 1-4 to install the parts.
Note: To clean the bearing housing and apply adhesive on
the outer race of bearing is necessary.
B
A
C
