POL
Y
V
BEL
T 430 J12 REPLACEMENT
PROCEDURE
T
ools requir
ed:
Philips
screwdriver
5-9
Hex key (6mm)
Hexagonal
socket wrench
(19&13mm)
Puller
Adjustable
wrench
Procedur
e:
1
Remove all of the covers.
(except the left cover).
2
Remove the pedal arm and crank
3
Loosen the screws then
remove poly v belt and
replace it with a new
one
4
Reverse step 1-3 to
install the parts.
A
27
29
