Johnson JPC-5100 - Poly-V Belt 430 J12

POLY V BELT 430 J12 REPLACEMENT PROCEDURE (JPE5100)
Tools required:
u Philips
screwdriver
u Hex key (6mm)
u Hexagonal
socket wrench
(19&13mm)
u Puller
u Adjustable
wrench
Procedure:
1 Remove all of the covers. (except the left cover).
2 Remove the pedal arm and crank (refer to page 3-18 &
3-19)
3 Loosen the screws then
remove poly v belt and
replace it with a new one
4 Reverse step 1-3 to
install the parts.
A
3-21 Revision: 1.0 Date: 2001/06/01
