Johnson JPC-5100 - Roller

ROLLER REPLACEMENT PROCEDURE (JPE5100)
Tools required:
u Philips
screwdriver
u Hex key (4mm)
Procedure:
1. Remove the all of cover.
2. Move the pedal arm back
then pick up it.
3. Loosen the screw (A)
holding the wheel to the
frame with the hex key
(4mm), and then replace it
with a new one.
4. Reverse the steps to
install the side cover.
A
3-24 Revision: 1.0 Date: 2001/06/01
