542933-UIM-C-0112
22 Johnson Controls Unitary Products
Exporting Log File
Clearing a Log Entry
New Event Entry
Press the Export button to export the displayed
log information. Using this function gives the user
the ability to save the log of a Touch Screen Com-
municating Control for future reference.
If the export function is selected the user will be
prompted to insert a USB device. Once the
device is inserted, the Touch Screen Communi-
cating Control will export the log information.
Do not remove the USB device until prompted.
Press the Clear button to delete all of the dis-
played log entries. When the clear button is
pressed, the Touch Screen Communicating Con-
trol will delete the log entries per the sort selec-
tion. For example, if “All” is selected in the sort
screen, all of the log entries that have been saved
on Touch Screen Communicating Control will be
cleared (deleted).
Press the “New” button to create a new log entry.
When the “Edit” button has been pressed the key-
board will pop up to allow the user to manually
input a log entry. This can be used to keep track
of home service, visits, maintenance, etc. For
example, the user can check to see when the last
A-Coil cleaning had taken place (if entered at time
of cleaning).
