Joie gemm Installation Instructions

2120
INSTALLATION
INSTALLATION
If the car is not fitted with
a child restraint anchorage
point:
For sedans only - drill a 9
mm hole in the parcel shelf
on the centre line of the
seating position as shown
on page 22.
Install the anchor bolt as
shown opposite.
It is recommended that this
installation be carried out by
a child restraint tting station
or licenced motor mechanic.
Attachment
Bolt
Spacers
(if required)
Anchor
Fitting
Vehicle
Metal
Structure
Vehicle Trim
FRONT OF VEHICLE
Lock
Washer
Nut
Reinforcing
Washer
Installation — Tether Anchorage
Use with Strollers
This Joie
™
child restraint can attach to Joie strollers using
adapters. Instructions are included with the adapters, which
are sold separately.
For vehicles other than sedans - In Australia, consult your
nearest child restraint tting station or trafc authority for
vehicle inspection to nd the best, correct position for the
placement of the anchorage point, and for the correct at-
tachment bolt length and use of spacers.
In New Zealand, consult the agent for the vehicle.

Joie gemm Specifications

General

Group	0+
Weight Capacity	0-13 kg
Harness Type	5-point harness
Side Impact Protection	Yes
Testing Certification	ECE R44/04
Weight	4 kg
Installation	ISOFIX or seat belt
Compatible with Strollers	Yes, with Joie strollers and others using Maxi-Cosi style adapters
