JORVIK TRICYCLES
Seat Post Assembly
Seat Installation: Insure the mounting clamp is
mounted on the frame over the hole on the seat.
Slide the seat base into the hole and adjust to the
desired height. Push down the lever on the clamp
to secure the seat in the mounting hole.
**Please make sure the washer‘s finger are assembled correctly. (please assemble like below picture, if
the finger isn’t assembled correctly the front wheel will be inclined to one side) . Check that the wheel
is centered into the fork and the disk is free in the brake caliber. Ensure the wheel turns freely. Tighten
the nuts with a spanner. Do not over tighten.
Page | 6
Assembly Instructions
Carefully remove the trike from its box.
On a clean material or clean floor, put the tricycle upside down to assemble the front
wheel. Loosen the nuts from the front axle. Slide the wheel into the slots at the end of the
forks. Make sure the disk for the brake slides into the front brake caliber cleanly.
Front Wheel Assembly Instructions
Ensure the wheel motor waterproof
patch cord fits together according to the
arrows which indicates the direction (As
the right picture shows) Press together
firmly.
For the hydraulic disc brake, front wheel
assembly is the same as above
