JORVIK TRICYCLES
1. Match the fender hole to the front fork hole. Insert
the light support and hexagon socket head cap screw
like the below picture then tighten the screw.
Page | 7
Assembly Instructions
How to assemble the front light and front fender
2. Match the light
hole to the support.
Insert the cross head
cap screw through
and tighten the screw.
3. The light is now
successfully
assembled.
4. Match the fender stay to the fork hole and tighten the
screw. (Same on the other side). Then the fender assembly is
now complete.
Handlebar Assembly
Put the Stem into the frame head tube，As the picture shows.
Use allen key to tighten (clockwise rotation).
