JORVIK TRICYCLES
Page | 8
Pedal Assembly
L or R on the pedal axle.
L means left pedal. R means right pedal.
Tighten clockwise for the right
pedal and anti-clockwise for the
left pedal.
Congratulations you have now assembled your e‐trike!
01 Handle bar 18~25
02 Stem 18~25
03 Saddle 18~25
04 Seat post 18~25
05 Front hub 40~45
06 Rear hub 18~20
07 B.B.Parts 40~45
No. Parts Torque required (N.M)
Recommended Torque for main part’s assembly
