35
8 SPECIFICATIONS
General
Frequency range: 154 – 163 MHz
Channel spacing: 25kHz (12.5kHz optional)
Operating temperature range: –20 to +55°C.
Battery life: > 8 hours (Lithium battery,
2W power output, 10-10-80)
> 7 hours (1500mAh NiMH battery,
5W power output, 5-5-90)
Antenna connector: SMA
Microphone connector: 2.5mm jack (Tron TR20 PLUS)
Headset connector: 3.5mm jack (Tron TR20 PLUS)
AF output power internal: >200mW.
AF output power external: >100mW.
Size: 62mm wide x 160mm height x 41mm depth
Weight: Approx. 420g with NiMH battery
Approx. 350g with Lithium battery
Receiver
Maximum usable sensitivity: < 1µV for 20dB SINAD
Adjacent channel rejection: > 70dB
Blocking: > 90dB
Spurious response: > 70dB
Harmonic distortion: < 5%
Intermodulation rejection: > 68dB
Transmitter
RF output power: 1W (Lo) / 5 W (Hi) Tron TR20 PLUS
1W (Lo) / 2 W (Hi) Tron TR20 GMDSS
Harmonics and spurious: < 0.25µW
Frequency error: < ±1.5kHz
Adjacent channel power: < -70dBc
Charger
Dual slot fast charger with trickle charging.
Operates on 12 –24 DC, or 115/230VAC with external mains adapter.
Wall and table mountable.
Size: 155mm wide x 69mm height x 83mm depth
Weight: Approx. 300g
