JPI EDM-930 - Component Parts

FAA Approved Installation Manual for the Report No 908
EDM-900 and EDM-930 Page 31 of 55 Rev I
Primary Engine Data Management System Date 1-18-2013
39. Component Parts
Twin engine
-4 Cyl -6 Cyl -7 Cyl -8 Cyl -9 Cyl
Display EDM-930 P/N 790000-C-(xxx) 1 1 1 1 1
Display EDM-900 P/N 790000-A-(xxx) 1 1 1 1 1
EGT probe KIT PN 11800 8 12 14 16 18
TIT probe with option KIT 12000 1 1 1 1 1
CHT probe KIT PN 12600 8 12 14 16 18
OAT probe with option KIT 12200 1 1 1 1 1
IAT probe with option KIT 11200 1 1 1 1 1
Carb temp probe KIT 11900 1 1 1 1 1
Oil Temp probe with option KIT 12500 PN 500409 1 1 1 1 1
Oil pressure sender KIT 14600 PN 159936A 1 1 1 1 1
Fuel pressure sender KIT 14500 PN 159935A 1 1 1 1 1
Fuel pressure differential sender Kit 14800 PN 159938 1 1 1 1 1
Ammeter shunt KIT 13000 PN 159920 1 1 1 1 1
Fuel Flow transducer PN 700900-1 1 1 1 1 1
Fuel Level sender option 1 1 1 1 1
MAP KIT 14400 PN 159934A 1 1 1 1 1
RPM one of P/N 420815-1 or,-2 1 1 1 1 1
RAD P/N-790749 1 1 1 1 1
Component Parts List for EGT (KIT 12800), TIT (KIT 12000) Probe
1 Thermocouple type K probe PN M-111
1 Stainless Steel Clamp Thimble
1 Stainless Steel Exhaust Seal Washer
1 Stainless Steel Screw Type Clamp
2 Ring Terminals
2 Screws and nuts 6-32 X 1/4
1 Fiberglass tube 3/8” x 5”
Component Parts list for CHT KIT 12600
1 Bayonet Probe Thermocouple type K Spring loaded PN 5050-T
1 Or Gasket thermocouple probe type K PN MM-113
2 Ring Terminals
2 Screws and Nuts 6-32 X 1/4"
1 Fiberglass tube 3/8” x 5”
Component Parts list for IAT (KIT 11400) probe
1 Thermocouple type K probe PN M-111
1 Stainless Steel Clamp &Thimble
1 Stainless Steel Exhaust Seal Washer
Component Parts list for OAT (KIT 1220) probe
1 P/N 400510, OAT probe
2 Ring Terminals
2 Screws and Nuts 6-32 X1/4"
Fiberglass tube 3/8” x 5”
Component Parts list for CARB (KIT 11900) probe
1 P/N 400128, CARB probe
2 Ring Terminals
2 Screws and Nuts 6-32 X1/4"
