FAA Approved Installation Manual for the Report No 908
EDM-900 and EDM-930 Page 32 of 55 Rev I
Primary Engine Data Management System Date 1-18-2013
1 Fiberglass tube 3/8” x 5”
Component Parts list for OIL Temperature probe (KIT 12500)
1 P/N 400509 OIL probe
1 AN900-10 crush washer
2 Ring Terminals
2 Screws and Nuts 6-32 X 1/4"
1 Fiberglass tube 3/8” x 5”
Component Parts list for Kit 14800 Differential Fuel Pressure (only if required by POH)
1 P/N 159938 Fuel pressure sensor
1 P/N 159961 Clamp, Loop Cushioned
1 P/N 174204 Connector MS 3116F8-4S
Component Parts list for Oil Pressure sensor KIT 12400
1 P/N 159936A Oil Pressure sensor
1 P/N 159961 Clamp, Loop Cushioned
1 P/N 174402 Connector Pack 3 Pin and Terminals
Component Parts list for Fuel Pressure Sensor KIT 14500 (only if required by POH)
1 P/N 159935A Fuel pressure sensor
1 P/N 159961 Clamp, Loop Cushioned
1 P/N 174402 Connector Pack 3 Pin and Terminals
Component Parts list for ampere shunt
1 P/N 159920 100 amp shunt
2 Ring Terminals
Component Parts list for Fuel Flow Transducer
1 fuel flow transducer, 201 or 231 PN 700900-1,-2
8 inches of 1.5” dia. fire sleeve
1 3-pin connector housing
3 female pins
2 AN816-4-4 fittings (Continental) or AN816-4-6 (Lycoming)
Component Parts list for MAP sensor KIT 14400
1 P/N 159934A Manifold pressure sensor
1 P/N 159961 Clamp, Loop Cushioned
1 P/N 174402 Connector Pack 3 Pin and Terminals
Components Parts list for RPM sensor P/N depends on Magneto make and model
Bendix magneto -20,120………….P/N 420815-2
Slick magneto 4000 or 6000………P/N 420815-1
40. Weight and Balance Data
Indicator PN 790000(-A) EDM-900 2.0 Lbs
Indicator PN 790000(-C) EDM-930 3.0 Lbs
EGT / TIT / CDT / IAT / OAT probe 2.0 oz. each / 0.125 lbs
CHT / Oil Temperature probe 1.5 oz. each / 0.094 lbs
4/6 Cylinder Harness 8 ft. 14.0 oz. each / 0.88 lbs
RPM 1.5 oz each / .094 lbs
MAP 5.0 oz / 0.42 lbs
Fuel Pressure Sender 5.0 oz / 0.42 lbs
Oil Pressure Sender 5.0 oz / 0.42 lbs
Harness each 1.0 Lbs
