Base Unit
Bluetooth
Pairing Button
PC/TEL
Selection
Microphone
Mute Button
Microphone
Volume
Compatibility
Switch
Mini ‘B’ USB/Bluetooth
Module Drawer
Bluetooth Button This function works when the Bluetooth module is inserted
PC/TEL Selection This function works when the USB cartridge is inserted
Microphone Mute Button Press to mute the call
Microphone Volume Yourheadsethasautomaticaudioconguration,(thiscantakeafew
minutes to settle) however, if required, you can adjust the volume
level for the speakers and microphone to suit
Compatibility Switch Select ‘1’ or ‘2’ until a dial tone is heard via the telephone connection
DC Jack Connect Power Adapter to DC Jack
AUX port ConnectionforHandsetLierorEHSAdapter(optionalextra)
Telephone Port Connect telephone cord to the headset port or handset port of a
telephone / base unit
Handset Port Plug Handset cord from the phone to Handset port
DC Jack AUX Port
Handset Port
Telephone Port
