1.3.8. Please do not look at the output window anytime when power on, and wear laser
safety goggle when operating the fiber laser.
1.3.9. YDFLP-E-60-M7-L1-R contains 17 wave-forms: CW, 2ns, 4ns, 6ns, 9ns, 13ns, 20ns,
30ns, 45ns, 60ns, 80ns, 100ns, 150ns, 200ns, 250ns, 350ns, 500ns.
Other pulse width is available for customization request.
1.4 YDFLP Product Naming Convention
Table 3 Naming Convention for Pulsed Fiber Laser
YDFLP – X – XX – XX – X – X
1 2 3 4 5 6
1.4.1. Product Name：Ytterbium Doped Fiber Laser Pulse (YDFLP)
1.4.2. Product type
1.4.3. Average Output power
1.4.4. Pulse Characteristics:
M series - adjustable pulse width
LP series - fixed pulse width
1.4.5. Optical Fiber attributes：
M: Near single mode, M²＜1.5
L: Low mode, M²＜1.8
H: High mode, M²＞2.5
1.4.6. Additional function：
R: Built-in red pilot laser
Examples：
YDFLP-E-50-LP-L: Type E LP, using low mode type of optical fiber with nominal output power
50W.
YDFLP-200-M7-H-R: Customized M7, using high mode type of optical fiber with the nominal
output power 200W, built-in red pilot laser.
