XF421EX MANUAL • INTRODUCTION 2: Features
INTRODUCTION 2:Features continued
517 Servo
• A .03ms deadband amplifier insures accurate
neutral centering.
• Low current drain.
• Ball bearing supported ouput shaft
• An indirect drive feedback potentiometer gives
additional protection from vibration.
SERVO FEATURES2.3
SERVO LAYOUT
2.4
Servo Mounting Flange
Rubber Grommets
Rubber Grommets
Servo Case
Servo Lead w/Connector
Servo Output Shaft
Servo Mounting Flange
Servo Arm/Horn
Servo Arm Retaining Screw
Servo Eyelet
Top View
