6
XF421EX MANUAL • INTRODUCTION 3: Specifications
INTRODUCTION 3:Specifications
SYSTEM SPECIFICATIONS
TRANSMITTER SPECIFICATIONS
3.1
3.2
SYSTEM NAME XF421EX
TRANSMITTER BODY XF421EX
RECEIVER R600
CHARGER NEC-221
AIRBORNE BATTERY 4N-600
SERVOS NES-517BBX4
ACCESSORIES Mini Switch
12" Aileron Extension
Servo Accessories
Instruction Manual
TYPE AIRPLANE
MODEL NUMBER XF421EX
ENCODER 5 Channel Computer System
RF 50/53/72 MHz
MODULATION PPM (FM)
OUTPUT POWER Approximately 1 Watt
CURRENT DRAIN 200mA
POWER SOURCE 1.2Vx8 Nicad (9.6V) 600mah
OUTPUT PULSE 1000-2000 (1500 Neutral)
TYPE AIRPLANE
SERVO SPECIFICATIONS3.3
TORQUE (oz./in.) 40.3
SPEED (sec.) .25
WEIGHT (oz.) 1.47
SIZE (in.) (W x L x H) 0.73 x 1.52 x 1.32
BB YES
MOTOR 3-Pole Ferite
TYPE 517BB
