JRC JAN-9201 Installation Manual

1.Overview > 1.3 Components
1-6
1.3 Components
A list of components and optional accessories is shown below.
Components of the Display Unit
T ype name Q' ty Re marks
(JMR-92XX/JAN-92XX) NWZ-208 26inch LCD monitor
(JMR-72XX/JAN-72XX) NWZ-207 19inch LCD monitor
(JMR-92XX/JAN-92XX) NWZ-208-TP Option 26inch
(JMR-72XX/JAN-72XX) NWZ-207-TP Option 19inch
NCM-928 1 Standard Equipment
NBD-913 1 Standard Equipment
NDC-1590 1 Standard Equipment
8GB System SSD CDD-752 1
256GB Data SSD CDD-753 1
DVD Drive CDD-754 1
HASP CYC-344 1
e-Token CYC-735 1
Central Processing Circuit CDC-1410 1
CCU Interface Circuit CMH-2406 1
CCU Interface Terminal CQD-2286 1
CCU Interconnection CML-902 1
COM Express Board CMC-1406 1
WES7P Licence CYC-847 1
TMSL Licence CYC-848 1
NCE-5605 1 Standard Equipment
Operation Circuit A CCK-1050 1
Trackball CCK-1060 1
Operation Circuit SW CCK-1069 1
Operation Circuit CN CCK-1070 1
TOPU Interconnection CMD-1103 1
NCE-5625 1
Option(NCE-5625 or CWB-1593)
Operation Circuit B CCK-1059 1
Option Keyboard CCK-1061 1
KOPU Interconnection CMD-1106 1
CWB-1593 1
Option(NCE-5625 or CWB-1593)
QUINT-PS/1AC/24DC/20 - 1
QUINT-BAT/24DC/3.4AH - 1
QUINT-DC-UPS/24DC/20 - 1
ME-MAX-NEF/QUINT20 - 1
NQE-1143 1 Option
Serial LAN Circuit CMH-2370 max 2 Option
Analog Option Circuit CMJ-560 1 Option
Gyro Interface Circuit CMJ-554 1 Option
Radar Interface Circuit CQD-2273 1 Option
Scanner AC Power Cable CML-836AC
Scanner AC Power Cable(F) CML-836ACF
Scanner DC Power Cable CML-836DC
Scanner DC Power Cable(F) CML-836DCF
NQA-2443 max 2
Option
In case of standalone type
26inch:max 2
19inch:only 1
16Port Switch HUB CQL-221 1
Sensor LAN Switch Interconnection CML-841 1
UPS Option
Junction
Box
1
Any one of these cables
include to the
CQD-2273
Sensor LAN
Switch Unit
Included in the
NQA-2443
Included in the
NDC-1590
Trackball
Operation
Unit
Inclueded in the
NCE-5605
Keyboard Operation Unit Included in the
NCE-5625
Large Tray
Unit
LCD
monitor
1
Touch Panel
monitor
Control
Unit
Power Supply Unit
Central Control
Unit
