9ņ3
Table 9-4 List of Route Error Messages and Warnings
Message Class Description ALR No.
Radar Alarm(In) Alarm Targets have entered the radar alarm range. 933
Radar Alarm(Out) Alarm Targets have left the radar alarm range. 934
Route(Approach) Alarm Approach the route. 938
Route(Break Off) Alarm Out of the route. 939
WPT(Arrival) Alarm Arrive at way point. 936
WPT(Break Off) Alarm Out of the way point. 937
ALR No: Unique alarm number in ALR sentence and ACK sentence.
Table 9-5 List of Operational Error Messages and Warnings
Message Class Description ALR No.
Can't Transmit INFO
Transmission cannot be executed.
Tried to transmit within 5 second after standby or when the
transmitter-receiver has any trouble.
Card Full INFO Card capacity insufficient.
Delete Failed INFO Data deletion from the card failed.
Format Failed INFO Card format failed.
In Use INFO Data cannot be deleted / changed because it is being used now.
In Use INFO Data has been inputted.
Invalid Card INFO Card is not valid.
Invalid Data INFO
The value is invalid.
Tried to enter any data beyond its range.
MAX Point INFO
The maximum number of points has been reached.
Tried to enter navigation information beyond the specified.
No Card INFO Card not detected yet.
No Position Data INFO
There is no position data.
Mark or line input when the latitude and longitude is invalid.
No Heading Data INFO
There is no bearing data.
Target tracking operation or TM selection when bearing data is
invalid.
Not Allowed INFO General operation error.
Out of Bounds INFO The latitude cannot be displayed on the map.
Out of Bounds INFO The latitude is outside the displayable latitude range.
Out of Range INFO Out of operation range.
Read Failed INFO Data load from the card failed.
Write Failed INFO Data write to the card failed.
ALR No: Unique alarm number in ALR sentence and ACK sentence.
