9ņ11
Table 9-11 Circuit Block to be Repaired (JMA-5208HS)
Location Circuit Block Type Remarks
Scanner Motor with gear CBP-169 DC brushless motor
Scanner Modulator CME-339 Excluding Magnetron
Scanner Receiver NRG-226 Including CAE-475-1
Processor Radar processing circuit CDC-1350
Processor DSP circuit (TT) NCA-877A
Processor Power supply terminal circuit unit NBD-866A
Processor AIS processing circuit NQA-2155
Operation panel unit Operation circuit CCK-979
Operation panel unit PS2 connector circuit CQC-1204
Display Brilliance control circuit CCK-970 Brilliance controller
NSK unit Gyro IF circuit CMJ-304E
Table 9-12 Circuit Block to be Repaired (JMA-5209)
Location Circuit Block Type Remarks
Scanner Motor CBP-218 DC Brush motor
Scanner Compound Modulator Circuit CME-386A Excluding Magnetron
Scanner Receiver Unit NRG-239 Including CAE-548
Processor Radar processing circuit CDC-1350
Processor DSP circuit (TT) NCA-877A
Processor Power supply terminal circuit unit NBD-866A
Processor AIS processing circuit NQA-2155
Operation panel unit Operation circuit CCK-979
Operation panel unit PS2 connector circuit CQC-1204
Display Brilliance control circuit CCK-970 Brilliance controller
NSK unit Gyro IF circuit CMJ-304E
