1-1
The proper installation of the radar equipment is critical in ensuing its effective and reliable performance as
well as facilitating maintenance and repair. Therefore, carefully install the radar equipment by following the
procedures below:
1) Install the scanner as high as possible while taking the scanner's weight into consideration.
2) It is preferable to install the display unit in the wheel house to facilitate observations.
3) Available cable lengths for installing the radar JMA-5200MK2 are as shown in the table below.
Request an appropriate cable from JRC beforehand. A cable longer than the sufficient length may
degrade radar performance, so give it careful consideration when planning the installation.
Code No. Cable length (number of cores)
CFQ6912-10 10 m (19 cores)
CFQ6912-15 15 m (19 cores)
CFQ6912-20 20 m (19 cores)
CFQ6912-30
30 m (19 cores)
CFQ6912-40
40 m (19 cores)
CFQ6912-50
50 m (19 cores)
CFQ6912-65
65 m (19 cores)
