3-39
3.14 TARGET TRACKING (NCA-877A)
(OPTION)
Install the target tracking unit in the processing unit according to the procedures below:
1) Equipment/connection
(1) Remove the processing unit cabinet cover.
(2) Connect the target tracking unit's connector to a connector shown in the following photograph.
(3) Fasten four screws shown in the following photograph to securely fix the target tracking unit.
(4) Attach the processing unit cabinet cover and complete the installation of the target tracking unit.
