3-47
3.17
COASTLINE
ROM
CARD/MEMOR
Y
CARD
below: Install the coastline ROM card
and the memory card accord
ing to the procedures below:
(1)
Rem
ove the rubber packing located at the front
side of the processi
ng unit cabinet, as shown in the
following photograph, an
d expose the car
d slot.
Rubber packing
Card slot
