3-38
3
3.13 POWER SUPPLY (NBA-5111) (OPTION)
If the ship's mains are alternating current, use the power supply. The power supply can be used for both
100/110/115 VAC and 200/220/230/240 VAC of the ship's mains, but the input connector and the
connecting bar must be changed.
Input connector Connecting bar
INPUT VOLTAGE
CN105 CN104 1-2 2-3 4-5
AC100V
AC105V㨪110V
AC115V㨪120V
AC200V
AC210V㨪220V
AC230V㨪240V
