3-8
3
3.5 INSTALLATION OF THE CABLE
(CFQ-6912) BETWEEN THE RADAR
PROCESS UNIT AND THE SCANNER
The cable CFQ-6912 is used to connect the radar process unit to the scanner.
For this radar equipment, use the following cables having a connector.
Cable length JRC code Remarks
10m CFQ-6912-10 Option
15m CFQ-6912-15 Option
20m CFQ-6912-20 Option
30m CFQ-6912-30 Option
40m CFQ-6912-40 Option
50m CFQ-6912-50 Option
65m CFQ-6912-65 Option
Cable CFQ-6912-**
Connector on both sides
To Next Page
