4.20 DISPLAYING GPS RECEPTION STATUS
The reception status of GPS (GPS/DGPS/WAAS) which is connected to radar processor unit is displayed.
This setting is enabled when a JRC’S GPS/DGPS/WAAS is connected to the GPS connector of processor unit.
This function cannot indicate with transmission state.
Procedures 1. Press [RADAR MENU] key.
The Radar Menu will appear.
2. Press [7] key.
NAV Equipment Setting Menu will appear.
3. Press [7] key.
GPS Setting Menu will appear.
4. Press [4] key.
GPS Status Menu will appear.
<The alternative procedure for steps above>
1. Hold down [RADAR MENU] key.
The Code Input Menu will appear.
2. Press [0] key.
3. Move the cursor onto the “ENT” button in the Code Input menu, and
press [ENT] key.
The Adjust Menu will appear.
4. Press [6] key.
NAV Equipment Setting menu opens.
5. Perform steps 3 and 4 in the “Procedure” above.
