8─70
8.6 Setting
yyyy
yyyy
8
NAV Equipment Setting
1. Set GYRO
0.0°
2. Heading Equipment
GYRO
MAN
0. EXIT
3. Speed Equipment
0.0kts
4. Manual Speed
5. MAG Compass Setting
6. Set/Drift Setting
7. GPS Setting
Ship Speed Equipment Setting (Speed Equipment)
Procedures 1 Press [RADAR MENU] key twice.
The RADAR Menu will appear.
2 Press [7] key.
The NAV Equipment Setting Menu will appear.
3 Press [3] key.
4 Select a ship speed sensor from the
pull-down menu.
Types of selectable speed sensors:
1: Manual
2: Log
3: 2-axis log (NMEA signal: Speed over water)
4: 2-axis log (NMEA signal: Speed over
ground)
Exit 1 Press [RADAR MENU] key.
The menu will be closed.
z The manually entered speed is effective only when
“MANUAL” is set.
z 2-axis log cannot be effective when the sentence
VBW of NMEA0183 is not entered.
Attention
