JRC JMA-5220-7 User Manual

8─86
8.6 Setting
yyyy
yyyy
8
DGPS Setting
1. Mode
AUTO
0. EXIT
2. Frequency
5. Send Data
275.0KHz
3. Baud Rate (BPS)
50
4. DGPS Mode
ON
Status
No Beacon RCV connection
Frequency --- KHz
Baud Rate --- Baud
RSSI ---
[III] Setting of Communication Baud Rate with Beacon Station (BPS)
This setting can be made only when Manual is selected in 1. Mode.
Procedures 1 Press [RADAR MENU] key twice.
The Radar Menu will appear.
3 Press [7] key.
NAV Equipment Setting Menu will appear.
4 Press [7] key.
GPS Setting Menu will appear.
5 Press [2] key.
DGPS Setting Menu will appear.
6 Press [3] key.
From the pull-down menu, you can select the
following transmission speeds.
50bps
100bps
200bps
Set the desired communication speed.
7 After having entered the value, press
[5] key to transmit the setting contents
to the DGPS receiver.
Exit 1 Press [RADAR MENU] key.
The Main Menu will reappear.
