JRC JMA-5220-7 User Manual

5 TRX Setting － 1 PRF Fine Tuning
2 Jamming 3 Rotation Speed － 1 0.08uS/2250Hz
2 0.25uS/1700Hz 3 0.5uS/1200Hz 4 0.8uS/750Hz 5 1.0uS/650Hz
－ 1 0.07uS/2200Hz
2 0.2uS/2200Hz 3 0.4uS/1400Hz 4 0.8uS/750Hz 5 1.0uS/650Hz 6 1.2uS/520Hz
4 XMIT Repetition FREQ 5 Band Select
6 Inter Switch Setting － 1 Select TRX 7 NAV Equipment Setting － 1 Set GYRO
2 Heading Equipment 3 Speed Equipment 4 Manual Speed 5 MAG Compass Setting － 1 Heading Correction
2 Correct Value
6 Set/Drift Setting － 1 Correction
2Set 3 Drift
7 GPS Setting
－1
GPS Process Setting － 1 Position
2 Exclusion 3 Geodetic 4 Antenna Height 5 Fix Mode 6 DOP Level 7 Position Average 8 Master Reset 9 Send Data
2
DGPS Setting － 1 Mode
2 Frequency 3 Baud Rate(BPS) 4 DGPS Mode 5 Send Data
3
WAAS Setting － 1 Mode
2 Ranging 3 NG WAAS 4 WAAS Select Mode 5 WAAS No. 6 Send Data
4 GPS Status
8
Weather INFO Setting －
1 Display Weather INFO 2 SEL Observation Place 3 RX Message Display 4 RX Buzzer
