3.3.5 Overview of Menu Structure
The menu structure of this radar system consists of eight frequently used function
menus, one main menu, and one service man menu used for the installation
settings.
Software buttons for opening those menus are displayed in the menu area located
at the bottom ten of the display.
For each menu item and structure, see the menu list in the appendix.
To prevent incorrect use, enter the special code to open the service man menu. For
operating the service man menu, see Section 7.1.1 "How to Open the Serviceman
Menuļ¼Service Man Menuļ¼"
Frequently used functions
Main menu
Serviceman menu
TT Used for operating and setting the target tracking function.
Track Used for operating and setting the other ship trails function.
AIS Used for operating and setting the AIS display function.
Route Used for operating and setting the route function.
PI Used for operating and setting the parallel-index-line function.
AZ Used for operating and setting the automatic acquisition /
activate function.
U.MAP Used for operating and setting the user map function.
Main Used for operating and setting the functions.
This menu is used for operation and settings when a system is
installed.
It is not used during normal operation.The special code must be
entered to open the service man menu.
