7－18
JMA-7100 Instruction Manual > 7.SETTINGS FOR SYSTEM OPERATION > 7.2 SETTINGS
2) Perform the following menu open procedure to open the Sector
Blank setting menu.
→
→
3) Left-click the button in the menu.
The selected sector blank will be made.
4) Set the starting azimuth of the TNI blank by operating the [EBL]
dial, and left-click the button.
The start angle of the TNI blank will be set.
5) Set the ending azimuth of the TNI blank by operating the [EBL]
dial, and left-click the button.
The end angle of the TNI blank will be set.
7.2.4 Setting of Bearing Pulses from Scanner Unit (Output Pulse)
Set the output value of bearing pulses from the scanner unit. The system can set
2048 pulses or 4096 pulses. This setting is enabled only when the scanner unit of
25 or 30 kW is used.
Procedures
1) Open the Serviceman Menu.
2) Perform the following menu open procedure to open the Output
Pulse setting menu.
→
→
3) Set the number of pulses to be output by the scanner unit.
i
i. If a 10 kW antenna is used, 2048 is always set.
:2048 pulses per antenna rotation (Recommended value)
:4096 pulses per antenna rotation
2. Installation Menu
9. Next
2. TNI Blank
2. Make Sector
ENT
ENT
1. Adjust Menu
4. TXRX Adjustment
6. Output Pulse
2048
4096
