3－106
JMA-7100 Instruction Manual > 3.BASIC OPERATION > 3.8 APPLIED OPERATIONS
3.8.8 Set Navigation Data Display (Multi Window Setting)
By performing the following operation, it is possible to display navigation data of
the wind direction / velocity, water depth and the like, as a graph on the radar
display.
Procedures
1) Open the Multi Window Setting menu by performing the menu
operation below.
→
The Multi Window Setting menu will appear.
Detailed settings of the display are possible by changing the settings of each item.
3.8.8.1 DIR/DIST EXP Display
• Determine whether to expand the value display of cursor, EBL, and VRM.
• The value display is expanded in digital information area 2.
• When the cursor mark moves on the PPI, the display of cursor information is
expanded.
• When an EBL or VRM is operated, the value display of each marker is
expanded.
• While the menu is open, any display is not expanded.
3.8.8.2 Numeric NAV INFO
• Determine whether to display the numeric values of received navigation
information.
• One of two digital information areas is used to display data.
• When navigation data is displayed, the sizes of the target tracking (TT)/AIS
numeric data display areas are exclusively decreased.
• Navigation information of the water depth, water temperature, tidal current,
wind direction/velocity, and destination is displayed with numeric values.
• Left-click the button located at thelower righit of the display. The
navigation data display function is switched between On and Off.
: Does not expand any display.
: Expands the display in digital information area 2. The
expanded display remains for 5 seconds after the
operation of each marker, and then it will disappear.
: Expands the display in digital information area 2.
: Does not display the numeric values of navigation information.
: Displays the numeric values of navigation information in digital information area 1.
: Displays the numeric values of navigation information in digital information area 2.
Main
4. Multi Window Setting
Off
On
Always On
Target
Off
Area1
Area2
