JMA-7100 Instruction Manual > 3.BASIC OPERATION > 3.7 USE ROUTE FUNCTION
3－67
3
3.7 USE ROUTE FUNCTION
In this radar system, a destination mark set by navigation equipment can be
displayed, and a simple route can be created, displayed, loaded and saved. (To use
this function, navigation equipment must be connected to this system)
3.7.1 Display Route/Destination Mark (Select Route)
In this radar system, the following route and destination marks can be displayed.
Procedures
1) Left-click the button located at the lower right of the
radar display.
The Route Menu will appear.
2) Set the item.
The following route/destination mark display modes can be selected.
i
If radar video is poor visibility caused by route function, click the
Map button to turn off the Map function. Otherwise, press the
[DATA OFF] key to map displays temporarily off.
NOTE:
The user map function is available between latitudes of 85°N and 85°S.
Route : Route created in the radar system, ECDIS and GPS are displayed.
Destination mark : Destination marks sent from outside navigation equipment are
displayed.
: Route and destination marks are not displayed.
: Route saved in the system are displayed.
: Destination marks are displayed by using WPT data sent
from outside navigation equipment.
i
i. To display the mark on the radar display,
select. The
destination mark is displayed only when the Waypoint data is received from
outside by using the NMEA sentence (RMB,BWC,BWR).
: Route created in the ECDIS and GPS are displayed.
ii
ii. When the system display Route which are created in the ECDIS, following items
are not displayed.
• XTL
• Arrival Radius
• ROT
• Turn Radius
• Time Zone
• Sail
Route
1. Select Route
Off
Internal
NMEA
○WP
NMEA
ECDIS/GPS
To Next Page
