3.8.5.3 Setting display brilliance (Brilliance Setting)
For each Day/Night mode, background color outside the bearing scale,
background color inside the bearing scale, and color for characters, radar echo and
radar trails can be selected.
Procedures
1) Open the Brilliance Setting menu by performing the menu
operation below.
āć
āć
Display Brilliance Setting menu will appear.
Setting brilliance of each element
ā¢ Specify the brilliance for the element.
ā¢ Level4 indicates maximum brilliance and Level1 indicates minimum brilliance.
ā¢ The brilliance for the following elements can be specified.
: The brilliance of the radar video is selected.
: The brilliance of the radar trails is selected.
: The brilliance of the target symbol is selected.
i
i. Minimum level is Level0.(it means OFF)
: The brilliance of the range rings is selected.
: The brilliance of the EBL / VRM / PI is selected.
: The brilliance of the character and bearing scale is
selected.
: The brilliance of the own ship symbol, heading line, and
own ship vector is selected.
: The brilliance of the operation panel is selected.
i
i
Those selected brilliance can be saved for each Day/Night mode.
Main
7. Sub Menu
2. Brilliance Setting
RADAR Video
RADAR Trails
Target Symbol
Range Rings
EBL/VRM /PI
Character
Own Symbol /HL/Vector
Keyboard
To Next Page
