JMA-7100 Instruction Ma
nual
>
8.COUNTERMEASURE FOR TROUBLE ...
>
8.4 REPLACEMENT OF MAJO
R P
ARTS
8
ļ¼
23
8
ā¢
A Phillips screwdriver for 4 mm screw
ā¢
A Phillips screwdriver for 6 mm screw
[Replacement procedure]
1)
Loosen the four scr
ews and r
emove the cover
.
The screws are slotted captive screws.Use a
flatblade screwdriver.
2)
Remove the screws (six M4 screws) and slide
the modulator cover to the right to remove it.
R
em
ove the f
our
scr
ew
s.
Loosen t
he si
x screws.
M
odul
ator
cover
420
422
