Cancellation
1 Press the [EBL1] or [EBL2] key again.
The selected EBL display will disappear.
[II] Moving the Starting Point of EBL
The system provides three types of EBL starting points. Select one of them in accordance with
purpose.
:The EBL starting point is defined as the own ship's position.
C :The EBL starting point is moved and fixed on the radar display.
D :The EBL starting point is moved and fixed at the latitude and longitude.
To move the starting point of EBL
Procedures
1 Make EBL1 or EBL2 operable.
2 Press the [EBL] dial to set C or D for the EBL1 / EBL2 starting
point mode switching.
The selected EBL starting point mode is switched as shown below each time the dial is pressed.
3 Put the cursor on the EBL starting point is to be moved, and left-click.
The selected EBL starting point will be determined.
8
