2.13 Display Radar Trails (TRAILS)
Changing the length of the trail
Procedures
1 Put the cursor on the radar trails display time switching, and left-click.
Values of the length of the radar trail are switched.
Erasing Trails Data
Procedures
1 Hold down the radar trails display time switching for 5 seconds.
All the saved trails data will be erased. The system starts plotting trails in initial state.
If radar trails display time switching button is pushed for 2 seconds, a RADAR Trails Setting menu
will be displayed. Furthermore, data will be erased if it continues pressing.
Changing Motion Mode of Trails (Trails mode)
Procedures
1 Put the cursor on radar trails display true T / relative R switching,
and left-click.
The trails motion modes are switched.
If true motion (TM) mode is selected in azimuth display mode, only the true motion trails mode is
available.
12
