2.2 End the Operation and Power Off
Exit
1 Press the [TX / STBY] key.
The radar will stop transmission and the antenna will stop rotating.
Transmit upper left of the display changes to Standby .
2 Press the [POWER] key.
The system will be turned off.
2.3 Adjust Monitor Brilliance [BRILL]
Procedures
1 Obtain the best-to-see display with optimum brilliance by turning the
[BRILL] dial at the lower right of the LCD monitor unit.
In consideration of the ambient brightness, adjust LCD monitor brilliance that is high enough to easily
observe the radar display but does not glare.
3
