JRC JMA-9122-9XA Installation Manual

JMA-9100/7100 Installation Manual > 1.EQUIPMENT COMPOSITION > 1.1 GENERAL COMPOSITION
1－1
1
1.1 GENERAL COMPOSITION
1.1.1 JMA-9100 SERIES RADAR
*1Input voltage is selectable. '1' or '2' suffix is attached to model name of scanner
unit. '1' means AC100-115V(50/60Hz) and '2' means AC220-240V(50/60Hz) for
type of scanner unit NKE-1139, NKE-1130, NKE-1129-7,NKE-1129-9, NKE-
1125-6 and NKE-1125-9. Others are DC input.
*2HEATER OPTION is available at suffix 'D' exclude type NKE-2103.
Table1-1： JMA-9100 SERIES RADAR LIST OF COMPOSITION (Self-Standing TYPE)
MODEL SCANNER UNIT RADIATOR
PERFORMANCE
MONITOR
TRANSMITTERR
ECEIVER UNIT
DISPLAY
UNIT
AC-DC
CONVERTER
JMA-9133-SA NKE-1139 NJU-84 NTG-3230 NCD-4990
―
JMA-9132-SA NKE-1130
―
JMA-9123-7XA NKE-1129-7 NAX-16B-7 NJU-85 NTG-3225
JMA-9123-9XA NKE-1129-9 NAX-16B-9
JMA-9122-6XA NKE-1125-6 NAX-16B-6
―
JMA-9122-9XA NKE-1125-9 NAX-16B-9
―
JMA-9122-6XAH NKE-2254-6HS NAX-16B-6
― NBA-5135
(Built in a
display unit)
JMA-9110-6XA NKE-2103-6 NAX-16B-6
―
JMA-9110-6XAH NKE-2103-6HS NAX-16B-6
―
Table1-2： JMA-9100 SERIES RADAR LIST OF COMPOSITION (Desktop TYPE)
MODEL SCANNER UNIT RADIATOR
PERFORMANC
EMONITOR
TRANSMITTER
RECEIVER UNIT
DISPLAY UNIT AC-DC
CONVERTER
JMA-9133-SA NKE-1139 NJU-84 NTG-3230 Display unit:
NWZ-170
Radar Process
Unit:
NDC-1399-9
Operation Unit:
NCE-5163
―
JMA-9132-SA NKE-1130
――
JMA-9123-7XA NKE-1129-7 NAX-16B-7 NJU-85 NTG-3225
―
JMA-9123-9XA NKE-1129-9 NAX-16B-9
―
JMA-9122-6XA NKE-1125-6 NAX-16B-6
――
JMA-9122-9XA NKE-1125-9 NAX-16B-9
――
JMA-9122-6XAH NKE-2254-6HS NAX-16B-6
―
NBA-5135
JMA-9110-6XA NKE-2103-6 NAX-16B-6
―
JMA-9110-6XAH NKE-2103-6HS NAX-16B-6
―
