Cross Reference
i
Cross Reference
JMA-9133-SA
Tab l e1- 1 ： JMA-9100 SERIES RADAR LIST OF COMPOSITION (Self-Standing TYPE)
Tab l e1- 2 ： JMA-9100 SERIES RADAR LIST OF COMPOSITION (Desktop TYPE)
Scanner Unit: NKE-1139
Table1-5： JMA-9133-SA SCANNER and TRANSMITTER RECEIVER UNIT
2.1.2 2695110056
2.2.6 NKE-1139 type scanner
2.4 PRECAUTIONS
Transmiter Receiver Unit: NTG-3230
2.3.2 NTG-3230 type transmitter receiver
Display Unit (self standing): NCD-4990
Table1-11： NCD-4990/NCD-4990T DISPLAY UNIT
3.1 INSTALLATION OF DISPLAY UNIT
3.3.1 Connections with NKE-1125,NTG-3225,NKE-1130,NTG-3230
OPTION Interswitch Unit: NQE-3141-2/4A/8A
5.1 INSTALLATION OF INTERSWITCH UNIT
Power Control Unit: NQE-3167
5.2.2 Connections to NKE-1125, NTG-3225, NKE-1130, and NTG-
3230
5.2.5 Connection to display unit
VDR I/F Kit: CQD-1891
5.3 INSTALLATION OF VDR
