JTS Mh-950 - Parts Identification & Accessories; 4-1 Receiver;; US-901 D US-9001 D; 4-2 Handheld Transmitter;; Mh-8900(i) Mh-950 Mh-960

WIRELESS MICROPHONE SYSTEM
7
8
4. Parts Identication & Accessories
4-1 Receiver // US-901D US-9001D
Power On/O switch
Up buon (frequency adjustment)
Down buon (frequency adjustment)
Set buon (frequency adjustment)
LCD Display
Volume control
DC socket for connection of main unit
AF output, jack socket (AF UNBAL)
Balanced XLR socket
Antenna input socket
Antenna
1
4
7
10
11
Interchangeable dynamic capsule
LCD display
Down buon
UP buon
Set buon
Baery tray buon
Baery tray
Power On/O switch
Mute On/O switch
4-2 Handheld Transmitter // Mh-8900(i) Mh-950 Mh-960
12
15
13
16
18
14
17
19
20
2
5
8
3
6
9
14
11
2
5
3
6
