JTS SIEM-2T User Manual

1. Important Cautions
ëMake all connections before plugging the unit into an
AC power outlet.
ëDo not leave the devices in a place with high
temperature or high humility.
ëDo not handle the power cord with wet hands.
ëKeep the devices away from fire and heat sources.
ëAvoid prolonged listening at overhigh volume. It may
cause injury to your ears.
2. Features
1
2
ëDeveloped with JTS advanced wireless technology.
ëWired and wireless design for ambience.
ëUHF PLL 16 selectable channels.
ëOver 80 meters of stable operation distance.
ëOutstanding signal to noise ratio.
ë Light weight engineering plastic chassis.
ëBuilt in limit to protect hearing.
3. Specification
3-1 SIEM-2T/SIEM-2R
1. Carrier Frequency Range.......
2. RF Output Power.....................
3. Nominal Frequency Deviation
(modulation).............................
4. Audio Input Impedance...........
5. Nominal Input Level................
6. Maximal Input Level................
7. LED Display.............................
8. Audio Input Connector...........
9. Loop Out Connector...............
10.Operation Voltage...................
502~960 MHz
10 mW/50mW(depending
on local regulation)
±40KHz
20kΩ
-20 dBV
0 dBV
AF Level, Channel
2 x Balanced XLR
2 x Ø6.3mm Balanced
Loop Out Socket
12-18 VDC, 300 mA
